WIFI Tuya Single/3-phase Power Clamp 80A/120A/200A/300A Multi-Function Residential Commercial Application

WIFI Tuya Single/3-phase Power Clamp 80A/120A/200A/300A Multi-Function Residential Commercial Application
WIFI Tuya Single/3-phase Power Clamp 80A/120A/200A/300A Multi-Function Residential Commercial Application
WIFI Tuya Single/3-phase Power Clamp 80A/120A/200A/300A Multi-Function Residential Commercial Application
WIFI Tuya Single/3-phase Power Clamp 80A/120A/200A/300A Multi-Function Residential Commercial Application
WIFI Tuya Single/3-phase Power Clamp 80A/120A/200A/300A Multi-Function Residential Commercial Application
WIFI Tuya Single/3-phase Power Clamp 80A/120A/200A/300A Multi-Function Residential Commercial Application
WIFI Tuya Single/3-phase Power Clamp 80A/120A/200A/300A Multi-Function Residential Commercial Application
WIFI Tuya Single/3-phase Power Clamp 80A/120A/200A/300A Multi-Function Residential Commercial Application
WIFI Tuya Single/3-phase Power Clamp 80A/120A/200A/300A Multi-Function Residential Commercial Application
WIFI Tuya Single/3-phase Power Clamp 80A/120A/200A/300A Multi-Function Residential Commercial Application
WIFI Tuya Single/3-phase Power Clamp 80A/120A/200A/300A Multi-Function Residential Commercial Application
$65.99
Ex Tax: $65.99
  • Stock: In Stock
  • Model: MZ005244
  • SKU: MZ005244
  • UPC: 681877470327

Available Options

Note: PC321 is a built-in antenna, the signal range is limited, the device can only be kept close to the WIFI, and keep the position about 5m.


Single phase: 200A/300A

3-phase: 80A/120A


Description:


The PC321-TY power clip helps you monitor the power consumption in your facility by connecting the clip to the power cord. It can also measure voltage, current, power factor, and active power.


Features:


• Support the automation of Tap-to-Run and other Tuya devices.

• Compatible with single/three-phase power.

• Three current changers for single-phase applications.

• Ability to measure voltage, current, power factor, active power and total energy consumption in real time.

• Ability to display the current temperature of the device on the app.

• Suitable for residential and commercial applications.

• Lightweight, easy to install and simple to operate.


Specifications:


Wireless Connectivity

Wi-Fi

802.11 B/G/N20/N40



RF Characteristics

• Operating frequency: 2.4GHz

• Internal Antenna

• Output Power: Up to +20dBm

Physical Specifications

Operating Voltage

100~240 Vac 50/60 Hz

Calibrated Metering Accuracy

• ≤ 100W Within ±2W

• >100W Within ±2%

Reporting Cycle

Every 2 seconds





Clamp diameter

• 80A: 10mm

• 120A: 16mm

• 200A: 20mm

• 300A: 24mm

Operating environment

•Temperature:-20 ℃ ~+55 ℃

•Humidity: ≤ 90% non-condensing

Dimension

86(L) x 86(W) x 37(H) mm


Package Included:


1 x Single/3-phase Power Clamp


>>Please Contact us to download the English manual<<
