50/60/80W High Power Co2 Glass Laser Tube Laser Accessories for Laser Engraving Cutting Machine
50/60/80W High Power Co2 Glass Laser Tube Laser Accessories for Laser Engraving Cutting Machine
$169.99
Ex Tax: $169.99
- Stock: In Stock
- Model: MZ004992
- SKU: MZ004992
Features
- Stable Output: Single-mode laser output with delicate spot, powerful laser energy, strong penetration, stable high-power performance and long service life.
- High-strength GG17 Glass Tube: Excellent heat & high temperature resistance, crack-resistant tube body.
- TEM00 Laser Technology: Metal head locks laser tube output mode to maintain standard TEM00 spot without deformation after long-term operation.
- Exclusive Electrode Process: Equipped with premium total reflection mirror & output mirror to reduce power attenuation and deliver high power density.
- Wide Compatibility: Water-cooled hermetic CO2 glass laser tube, replacement spare part for laser engraving, marking & cutting machines. Suitable for processing acrylic, fabric, leather, bamboo, wood and more materials.
General Specifications
| Item | Parameter |
| Product Name | CO2 Glass Laser Tube |
| Model | W1 |
| Rated Power (Optional) | 50W / 60W / 80W |
| Wavelength | 10.6μm |
| Control Mode | CNC |
| Current Type | DC |
| Max Marking Depth | 25mm |
Model Parameter Table
| Model | Length | Diameter | Standard Power | Max Power | Shelf Life (Year) | Working Hours |
|---|---|---|---|---|---|---|
| F50 | 1000mm | 50mm | 50W | 80W | 6 | 5000 hours |
| F60 | 1250mm | 60mm | 60W | 90W | 6 | 5000 hours |
| F80A | 1250mm | 80mm | 80W | 100W | 10 | 5000 hours |
Package Included
| Quantity | Accessory |
| 1 Pc | CO2 Glass Laser Tube |
More Detail
